Metro PCB Hand-Held Carriers CBC11C – 12-1/2″w x 17-1/2″l x 18-3/16″h (315x445x460mm)

Description

Metro PCB Hand-Held Carriers are the safe, efficient way to carry delicate printed circuit boards. The system features adjustable panels with 5/8″ (16mm) slide spacing that accommodate boards up to 1/8″ (3mm) thick.  High-temperature phenolic knobs can be used in applications with up to 400º F (204º C) continuous temperatures.

Model #CBC11C, 12-1/2″w x 17-1/2″l x 18-3/16″h (315x445x460mm).

• Units carry up to 20 full-size boards; optional double-sided center panels increase capacity of carriers.

• Stackable design permits up to three carriers of the same size to be stacked vertically, saving floor space.

• Units can be transported and stored on Metro Kitting Carts (see “Kitting Carts”.
• accommodates a maximum size of 13″ x 12″ (330x305mm) full-size boards, total capacity: (20).With the addition of the optional center panel this model will also accommodate (40) 12″ x 16″ (305x152mm) boards.
• Load Rating:  5 lbs. (2kg) per slide, not to exceed 75 lbs. (34kg) per carrier.

ESD Classification:  Conductive
